| 品 牌 | LODXY |
 |
| 品 名 | 整体合金65度2刃/4刃铣刀U型槽 | |
| 材 质 | 钨钢 | |
| HRC | 65° | |
| 涂 层 | TIAIN | |
| 螺旋角 | 45° | |
| 适用切削材料 | 钢，不锈钢，铸铁，石墨，钛合金，镍，耐热钢，低合金钢，高合金钢等 |
| 规格（mm） | 订货号 | 库存情况 | |||||
| 规格 | 直径 | 刃长 | 柄经 | 总长 | |||
| 标准长 | Φ1.0×3×4D×50L | 1.0 | 3.0 | 4.0 | 50.0 | XY600-001 | ● |
| Φ1.5×4×4D×50L | 1.5 | 4.0 | 4.0 | 50.0 | XY600-002 | ● | |
| Φ2.0×6×4D×50L | 2.0 | 6.0 | 4.0 | 50.0 | XY600-003 | ● | |
| Φ2.5×7×4D×50L | 2.5 | 7.0 | 4.0 | 50.0 | XY600-004 | ● | |
| Φ3.0×9×4D×50L | 3.0 | 9.0 | 4.0 | 50.0 | XY600-005 | ● | |
| Φ4.0×11×4D×50L | 4.0 | 11.0 | 4.0 | 50.0 | XY600-006 | ● | |
| Φ5.0×13×5/6D×50L | 5.0 | 13.0 | 5.0/6.0 | 50.0 | XY600-007 | ● | |
| Φ6×15×6D×50L | 6.0 | 15.0 | 6.0 | 50.0 | XY600-008 | ● | |
| Φ7×20×8D×60L | 7.0 | 20.0 | 8.0 | 60.0 | XY600-009 | ● | |
| Φ8×20×8D×60L | 8.0 | 20.0 | 8.0 | 60.0 | XY600-010 | ● | |
| Φ9×25×10D×75L | 9.0 | 25.0 | 10.0 | 75.0 | XY600-011 | ● | |
| Φ10×25×10D×75L | 10.0 | 25.0 | 10.0 | 75.0 | XY600-012 | ● | |
| Φ11×30×12D×75L | 11.0 | 30.0 | 12.0 | 75.0 | XY600-013 | ● | |
| Φ12×30×12D×75L | 12.0 | 30.0 | 12.0 | 75.0 | XY600-014 | ● | |
| Φ13×40×14D×100L | 13.0 | 40.0 | 14.0 | 100.0 | XY600-015 | ● | |
| Φ14×40×14D×100L | 14.0 | 40.0 | 14.0 | 100.0 | XY600-016 | ● | |
| Φ15×45×16D×100L | 15.0 | 45.0 | 16.0 | 100.0 | XY600-017 | ● | |
| Φ16×45×16D×100L | 16.0 | 45.0 | 16.0 | 100.0 | XY600-018 | ● | |
| Φ18×45×18D×100L | 18.0 | 45.0 | 18.0 | 100.0 | XY600-019 | ● | |
| Φ20×45×20D×100L | 20.0 | 45.0 | 20.0 | 100.0 | XY600-020 | ● | |
| 加长 | Φ4×15×4D×75L | 4.0 | 15.0 | 4.0 | 75.0 | XY600-021 | ● |
| Φ4×20×4D×100L | 4.0 | 20.0 | 4.0 | 100.0 | XY600-022 | ● | |
| Φ5×15×5/6D×75L | 5.0 | 15.0 | 5.0/6.0 | 75.0 | XY600-023 | ● | |
| Φ5×20×5/6D×100L | 5.0 | 20.0 | 5.0/6.0 | 100.0 | XY600-024 | ● | |
| Φ6×15×6D×75L | 6.0 | 15.0 | 6.0 | 75.0 | XY600-025 | ● | |
| Φ6×20×6D×100L | 6.0 | 20.0 | 6.0 | 100.0 | XY600-026 | ● | |
| Φ8×25×8D×75L | 8.0 | 25.0 | 8.0 | 75.0 | XY600-027 | ● | |
| Φ8×30×8D×100L | 8.0 | 30.0 | 8.0 | 100.0 | XY600-028 | ● | |
| Φ10×40×10D×100L | 10.0 | 40.0 | 10.0 | 100.0 | XY600-029 | ● | |
| Φ12×45×10D×100L | 12.0 | 45.0 | 12.0 | 100.0 | XY600-030 | ● | |
| 特长 | Φ6×40×6D×150L | 6.0 | 40.0 | 6.0 | 15.0 | XY600-031 | ● |
| Φ8×40×8D×150L | 8.0 | 40.0 | 8.0 | 150.0 | XY600-032 | ● | |
| Φ10×50×10D×150L | 10.0 | 50.0 | 10.0 | 150.0 | XY600-033 | ● | |
| Φ10×55×10D×200L | 10.0 | 55.0 | 10.0 | 200.0 | XY600-034 | ● | |
| Φ12×50×10D×150L | 12.0 | 50.0 | 12.0 | 150.0 | XY600-035 | ● | |
| Φ12×60×12D×200L | 12.0 | 60.0 | 12.0 | 200.0 | XY600-036 | ● | |
| Φ14×55×14D×150L | 14.0 | 55.0 | 14.0 | 150.0 | XY600-037 | ● | |
| Φ14×70×14D×200L | 14.0 | 70.0 | 14.0 | 200.0 | XY600-038 | ● | |
| Φ16×60×16D×150L | 16.0 | 60.0 | 16.0 | 150.0 | XY600-039 | ● | |
| Φ16×70×16D×200L | 16.0 | 70.0 | 16.0 | 200.0 | XY600-040 | ● | |
| Φ18×70×18D×150L | 18.0 | 70.0 | 18.0 | 150.0 | XY600-041 | ● | |
| Φ18×70×18D×200L | 18.0 | 70.0 | 18.0 | 200.0 | XY600-042 | ● | |
| Φ20×70×20D×150L | 20.0 | 70.0 | 20.0 | 150.0 | XY600-043 | ● | |
| Φ20×70×20D×200L | 20.0 | 70.0 | 20.0 | 200.0 | XY600-044 | ● | |
